WATER SOFTENER SERVICE • GUADALUPE
Water Fixers can test hardness, inspect an existing softener, and help with maintenance, repair evaluation, brine and resin issues, replacement planning, or a properly matched new system for a San Luis Obispo property.
A softener is the right tool for hardness. Other symptoms can belong to filtration, drinking-water treatment, plumbing, or the water heater instead.
Confirm untreated and treated hardness, then check settings, regeneration, brine behavior, bypass position, and resin performance before changing equipment.
Valve, bypass, brine, drain, control, and connection problems should be diagnosed before the system is written off.
Choose a model only after hardness load, daily demand, peak flow, plumbing, available space, and service access are understood.
GUADALUPE WATER HAS ITS OWN SOURCE CONTEXT
WATER FIXERS SOFTENER LINEUP
Water Fixers offers five softener models with different footprints, capacity, flow and control options. Use the tabs on each model to review Best Fit, Performance, Controls, Installation and Warranty. The home-size and household figures are typical guidance—not a substitute for checking the water, household demand and installation conditions.
COMPACT ALL-IN-ONE SOFTENER
A compact cabinet-style model with fixed-cycle programming for smaller households.
HOME SIZE
HOUSEHOLD
CAPACITY
FLOW
✓ All-in-one cabinet
✓ 18,000-grain capacity
✓ 5 GPM nominal flow
✓ Automatic meter regeneration
Sizing note: Square-footage and family-size figures are typical guidance from the supplied specification sheet. Water hardness, daily water use, simultaneous flow demand and plumbing conditions should also be considered when selecting a softener.
The home-size and household figures below are the typical guidance listed on the supplied specification sheet. Final sizing should also consider water hardness and actual household demand.
Typical home size
Less than 1,400 sq. ft.
Typical family size
1–3 people
System design
Cabinet model, all-in-one
Manufacturing
Import manufactured
Positioning
Entry level budget pricing
These are the treatment-media, capacity and flow figures listed for this model.
Resin volume
.75 cu. ft.
Resin type
8% Crosslink
Resin capacity
18,000 grains @ 9 lbs. Salt Regenerate
Nominal flow rate
5 gpm
Peak flow rate
8 gpm
Maximum working pressure
90 psi
This tab keeps the control-valve and regeneration terminology from the supplied specification sheet.
Control valve
Mechanical/Electronic Hybrid Control Valve
Programming
Digital Screen, Fixed Cycle, Hardness, Capacity, Salt Lbs., Time of Day, Time of Regeneration
Regeneration
Downflow Regeneration, Flow Meter Totalizer with Automatic Regeneration
Programming type
Fixed Cycle Programming
Use these dimensions and connection sizes as equipment-planning information. Site clearance and plumbing layout still need to be verified at installation.
Salt cabinet
36” H x 18” D x 10.5” W
Salt tank capacity
150 lbs.
Brine well
Safety Overflow Float
Resin tank
8” D x 35” H
Valve connections
13/16” Inlet and Outlet Ports
By-pass adapters
1/2”, 3/4”, 1”
Warranty terms below are reproduced from the supplied specification sheet.
Control valve
1 year — electronics, piston, seals, spacers, brine piston excluded
Resin tank
3 years
Salt cabinet
3 years
TWO-TANK WATER SOFTENER
A USA-manufactured two-tank model with electronic control and fixed-cycle programming.
HOME SIZE
HOUSEHOLD
CAPACITY
FLOW
✓ Two-tank design
✓ 24,000-grain capacity
✓ 7 GPM nominal flow
✓ Water Saving Factors
Sizing note: Square-footage and family-size figures are typical guidance from the supplied specification sheet. Water hardness, daily water use, simultaneous flow demand and plumbing conditions should also be considered when selecting a softener.
The home-size and household figures below are the typical guidance listed on the supplied specification sheet. Final sizing should also consider water hardness and actual household demand.
Typical home size
Less than 1,800 sq. ft.
Typical family size
1–4 people
System design
Two-Tank System
Manufacturing
USA Manufactured
Positioning
Budget Pricing
These are the treatment-media, capacity and flow figures listed for this model.
Resin volume
1.0 cu. ft.
Resin type
8% Crosslink
Resin capacity
24,000 grains @ 9 lbs. Salt Regenerate
Nominal flow rate
7 gpm
Peak flow rate
10 gpm
Maximum working pressure
90 psi
This tab keeps the control-valve and regeneration terminology from the supplied specification sheet.
Control valve
Electronic Control Valve
Programming
Digital Screen, Fixed Cycle, Hardness, Capacity, Salt Lbs., Time of Day, Time of Regeneration, Water Saving Factors
Regeneration
Downflow Regeneration, Flow Meter Totalizer with Automatic Regeneration
Programming type
Fixed Cycle Programming
Use these dimensions and connection sizes as equipment-planning information. Site clearance and plumbing layout still need to be verified at installation.
Salt cabinet
30” H x 14” D
Salt tank capacity
200 lbs.
Brine well
Safety Overflow Float
Resin tank
9” D x 48” H
Valve connections
1” Inlet and Outlet Ports
By-pass adapters
3/4”, 1”
Warranty terms below are reproduced from the supplied specification sheet.
Control valve
1 year — electronics, piston, seals, spacers, brine piston excluded
Resin tank
3 years
Salt tank
3 years
HIGHER-FLOW TWO-TANK SOFTENER
A larger USA-manufactured two-tank model with more resin capacity and higher service flow.
HOME SIZE
HOUSEHOLD
CAPACITY
FLOW
✓ 1.5 cu. ft. resin
✓ 36,000-grain capacity
✓ 10 GPM nominal flow
✓ 14 GPM peak flow
Sizing note: Square-footage and family-size figures are typical guidance from the supplied specification sheet. Water hardness, daily water use, simultaneous flow demand and plumbing conditions should also be considered when selecting a softener.
The home-size and household figures below are the typical guidance listed on the supplied specification sheet. Final sizing should also consider water hardness and actual household demand.
Typical home size
Less than 2,400 sq. ft.
Typical family size
1–4 people
System design
Two-Tank System
Manufacturing
USA Manufactured
These are the treatment-media, capacity and flow figures listed for this model.
Resin volume
1.5 cu. ft.
Resin type
8% Crosslink
Resin capacity
36,000 grains @ 9 lbs. Salt Regenerate
Nominal flow rate
10 gpm
Peak flow rate
14 gpm
Maximum working pressure
90 psi
This tab keeps the control-valve and regeneration terminology from the supplied specification sheet.
Control valve
Electronic Control Valve
Programming
Digital Screen, Fixed Cycle, Hardness, Capacity, Salt Lbs., Time of Day, Time of Regeneration, Water Saving Factors
Regeneration
Downflow Regeneration, Flow Meter Totalizer with Automatic Regeneration
Programming type
Fixed Cycle Programming
Use these dimensions and connection sizes as equipment-planning information. Site clearance and plumbing layout still need to be verified at installation.
Salt cabinet
30” H x 18” D
Salt tank capacity
300 lbs.
Brine well
Safety Overflow Float
Resin tank
10” D x 54” H
Valve connections
1” Inlet and Outlet Ports
By-pass adapters
3/4”, 1”
Warranty terms below are reproduced from the supplied specification sheet.
Control valve
1 year — electronics, piston, seals, spacers, brine piston excluded
Resin tank
3 years
Salt tank
3 years
HIGH-EFFICIENCY ALL-IN-ONE SOFTENER
An all-in-one USA-manufactured model with 10% crosslink resin, adjustable programming and up-flow regeneration.
HOME SIZE
HOUSEHOLD
CAPACITY
FLOW
✓ 10% Crosslink resin
✓ 36,000 grains @ 6 lbs.
✓ 12 GPM nominal flow
✓ Up-flow regeneration
Sizing note: Square-footage and family-size figures are typical guidance from the supplied specification sheet. Water hardness, daily water use, simultaneous flow demand and plumbing conditions should also be considered when selecting a softener.
The home-size and household figures below are the typical guidance listed on the supplied specification sheet. Final sizing should also consider water hardness and actual household demand.
Typical home size
Less than 2,500 sq. ft.
Typical family size
1–4 people
System design
Cabinet Model All-in-One
Manufacturing
USA Manufactured
Efficiency note
Ultimate Water and Salt Savings
These are the treatment-media, capacity and flow figures listed for this model.
Resin volume
1.5 cu. ft.
Resin type
10% Crosslink
Resin capacity
36,000 grains @ 6 lbs. Salt Regenerate
Nominal flow rate
12 gpm
Peak flow rate
15 gpm
Maximum working pressure
90 psi
This tab keeps the control-valve and regeneration terminology from the supplied specification sheet.
Control valve
Electronic Control Valve
Programming
Digital Screen, Fixed Cycle, Hardness, Capacity, Salt Lbs., Time of Day, Time of Regeneration, “Proportional Salt-brining”, “Variable Reserve Capacity”, Cycle Increment Programming
Regeneration
“Up-flow” Regeneration, Flow Meter Totalizer with Automatic Regeneration
Programming type
Adjustable Multi-Cycle Programming
Use these dimensions and connection sizes as equipment-planning information. Site clearance and plumbing layout still need to be verified at installation.
Salt cabinet
44” H x 20” D x 12” W
Salt tank capacity
200 lbs.
Brine well
Safety Overflow Float
Resin tank
12” D x 35” H
Valve connections
1” Inlet and Outlet Ports
By-pass adapters
1”
Warranty terms below are reproduced from the supplied specification sheet.
Control valve
1 year — electronics, piston, seals, spacers, brine piston excluded
Resin tank
3 years
Salt cabinet
3 years
PREMIUM HIGH-CAPACITY SOFTENER
The largest model in the supplied lineup, with 2.0 cu. ft. of 10% crosslink resin, higher flow and up-flow regeneration.
HOME SIZE
HOUSEHOLD
CAPACITY
FLOW
✓ 2.0 cu. ft. resin
✓ 48,000 grains @ 6 lbs.
✓ 14 GPM nominal flow
✓ 18 GPM peak flow
Sizing note: Square-footage and family-size figures are typical guidance from the supplied specification sheet. Water hardness, daily water use, simultaneous flow demand and plumbing conditions should also be considered when selecting a softener.
The home-size and household figures below are the typical guidance listed on the supplied specification sheet. Final sizing should also consider water hardness and actual household demand.
Typical home size
Less than 3,500 sq. ft.
Typical family size
1–6 people
System design
Two-tank System
Manufacturing
USA Manufactured
Efficiency note
Ultimate Water and Salt Savings
These are the treatment-media, capacity and flow figures listed for this model.
Resin volume
2.0 cu. ft.
Resin type
10% Crosslink
Resin capacity
48,000 grains @ 6 lbs. Salt Regenerate
Nominal flow rate
14 gpm
Peak flow rate
18 gpm
Maximum working pressure
90 psi
This tab keeps the control-valve and regeneration terminology from the supplied specification sheet.
Control valve
Electronic Control Valve
Programming
Digital Screen, Fixed Cycle, Hardness, Capacity, Salt Lbs., Time of Day, Time of Regeneration, “Proportional Salt-brining”, “Variable Reserve Capacity”, Cycle Increment Programming
Regeneration
“Up-flow” Regeneration, Flow Meter Totalizer with Automatic Regeneration
Programming type
Adjustable Multi-Cycle Programming
Use these dimensions and connection sizes as equipment-planning information. Site clearance and plumbing layout still need to be verified at installation.
Salt cabinet
40” H x 18” D
Salt tank capacity
350 lbs.
Brine well
Safety Overflow Float
Resin tank
12” D x 52” H
Valve connections
1” Inlet and Outlet Ports
By-pass adapters
1”
Warranty terms below are reproduced from the supplied specification sheet.
Control valve
1 year — electronics, piston, seals, spacers, brine piston excluded
Resin tank
3 years
Salt cabinet
3 years
Not sure which one fits? Start with the water and the household, then compare equipment. Open the complete Water Fixers softener comparison →
USE THE MODEL SELECTOR AS A FITTING TOOL
The model selector above keeps photos, fit, performance, controls, installation details and warranty information in one place. Use it to compare options after the water and household demand are understood.
The amount of hardness and the home’s daily water use determine the capacity required between regenerations.
The softener should support normal simultaneous demand without creating an avoidable restriction through the treatment equipment.
Cabinet/two-tank configuration, drain routing, bypass access, and service clearance can change which model is practical.
These are different service decisions and should not be collapsed into one sales recommendation.
For salt/brine care, settings, cleaning, regeneration checks, and confirming treated-water performance.
For leaks, valve/control faults, brine draw problems, drain issues, bypass trouble, or incomplete regeneration.
For poor repair value, recurring failures, unsupported parts, poor sizing, or equipment that no longer fits the property.
A softener should not be replaced simply because a different water-quality concern is present. Identify the treatment job first.
Choose the system by the problem it is designed to address.
For confirmed hardness and the mineral scale/spotting effects associated with hardness.
For defined whole-home goals such as applicable sediment, taste, odor, or disinfectant concerns. See whole-house filtration.
For dedicated drinking and cooking water. See San Luis Obispo RO service.
Hard water returned, salt use changed, the brine tank looks wrong, or the softener is leaking or not regenerating? Water Fixers can evaluate many existing water-softener brands across California’s Central Coast—even when the system was installed by someone else.
We diagnose the controls, valve, brine system, resin performance and surrounding plumbing before recommending repair, maintenance or replacement.
Tell us what you are seeing—scale, salt or brine changes, leaks, regeneration trouble or inconsistent soft water. We can test the water, check the equipment and narrow the next step without assuming replacement is necessary.
